Figure, Type and Size
EGUN4 is rectangular shape and the following is the indication of size.
EGUN4
image_egun1
EGUN4　02　07　L=1000
EGUN4：(Type)
02：(Thickness : mm. 02 means 2mm)
07：(Width : mm. 07 means 7mm)
L=1000：(Length : mm. 1000 means 1,000mm)
１．Quality Characteristic
Item Value Unit
Hardness Under 3.0 N/cm2
Surface
Resistance		 Room temperature Under 0.10 Ω
After 22 hours,
Temperature　70degrees C
Compression
Remain
(Distortion)		 After 22 hours,
Temperature 70
degrees C		 Under 20.0 %
Flame Retardant UL94V-0 ―
Adhesion Over 16.0 Ｎ/25㎜
